STAINLESS STEEL SPRAY WASH CABINET 3-PHASE, 200-415VAC, 50/ 60HZ

MODEL SWE-50030VS

2.2kw Stainless Steel Vertical Water Pump.

The all-stainless steel design* greatly improves the rust and corrosion resistance of the machine, making the service life of the spray wash cabinet longer.

  • . 24V AC control panel power
  • . Internal dimensions: 30” turntable; 38” job height; 1250 lbs. max weight capacity
  • . Low water level alarm and automatic Shut-off protect heating elements and water pump against low water levels
  • . Low water auto fill system will fill water automatically when the water level is low.
  • . Broken heater alarm and automatic shut-off
  • . Stainless steel oil skimmer allows longer use of solution whilst changing less frequently
  • . Sprocket drive that won't rob you of water pressure like water driven models can tend to do
  • . Slow 4-5 rpm gives a superior, more thorough cleaning performance over water driven models
  • . 2.2kw stainless steel Vertical pump that pumps a solid 68 gallons per min
  • . 50 gallons insulated solution tank provides an ample supply of water for extra heavy-duty parts
  • . 3 x 3 kw heating elements heating solution up to a maximum of 194F (90C) in approx. 2 hours
  • . 7-day/ 24hr timer included to eliminate early morning starts for you and your staff
  • . Full opening gasket free door as gaskets will often perish with long term exposure to steam
  • . Stainless Steel Removable tank fine filter screen allows for quick and easy cleaning and protects the water pump
  • . Optional biodegradable, non-caustic, heavy duty powdered detergent. ​

Features

  • . Simple Operation
  • . 0-60 Minute Automatic Timer
  • . 0-15 Minute Oil Skimmer
  • . Lower Water Level Sensor Alarm
  • . Lower Water Automatic Shut Off
  • . Turntable Jog Switch
  • . Sprocket Drive Turntable
  • . Stainless Steel turntable bearings
  • . Stainless Steel Spray Nozzles
  • . Stainless Steel Removable Fine Filter
  • . Stainless Steel Removable Parts Basket
  • . Stainless Steel Removable Parts Tree
  • . Accommodates Engine Crane Loading
  • . Gasket Free Door
  • . Heavy Duty Polyurethane Casters
  • . 3.0hp Stainless Steel Vertical Pump
  • . 1,250 lb Capacity Heavy Duty Stainless steel Turntable
  • . 2.75mm thickness SS304 stainless steel cabinet and door
*Specifications Subject to Change Without Notice
